SA...TK SA35T/K SA35ES Rod End Joint Bearing

Features of Rod End Bearing

SA 35 ES-2RS / SA35ES / SA35T/K

These rod ends joint bearings contain a spherical plain bearing with a steel/steel sliding contact surface combination and a double-lip contact seal on both sides. The bearing requires maintenance and can be relubricated via a grease fitting in the housing and via the shaft. The male thread is available with a left- (prefix SAL) or a right-hand thread. Some sizes have different fitting dimensions (SA(L)A series).

The rod end joint includes a bore head with an integral rod end forming a rod end seat for a spherical plain bearing. Typically, rod ends have left or right female (internal) or male (external) threads.

As standard, rod ends are supplied with a threaded shank with a right-hand thread. All rod ends are available with left-hand thread options, except for the rod ends with the designation suffix VZ019. These bearings are identified by the designation prefix L .

FAQ

Q: How do you pack the rod end bearings ?

• Each in plastic bag+ carton box + Wooden pallet

Q: Can i get the samples from you?

A: It is highly encouraged to ask for the samples for quality check.
